LATHE CAZENEUVE HB575 OF 2000-REBUILT
No longer available
LATHE CAZENEUVE HB575 OF 2000-REBUILT
€26,000
Description
Amutio Cazeneuve HB575 rebuilt lathe from 2000. Headstock spindle taper: Equipped with 250mm universal chuck and steady rest. Chuck and carriage guards and CE certified (RD1215/97). (Optional fairing) Optional display.
Specifications
| Condition | Used |
| Stock Number | 00006 |
| Diameter admitted on bench | 575mm. |
| Diameter allowed on carriage | 525mm. |
| Diameter admitted without transverse carriage | 300mm. |
| Height of points | 250mm. |
| Distance between points | 2000mm. |
| Inner diameter of the head shaft | 51mm. |
| Tailstock cone | CM-5 |
| Width of the bench | 400mm |
| Maximum travel of the cross carriage | 305mm. |
| Maximum course of the steerable carriage | 140mm. |
| Maximum travel of the tailstock reed | 150mm. |
| Number of headstock spindle speeds | 18. |
| Machine weight | 2200Kgs. |
| Machine dimensions | 3405x1175x1345. |
| Warranty | 1 year. |
